SD8530AS
PRIMARY SIDE REGULATOR WITH BUILT-IN HIGH VOLTAGE TRANSISTOR

    SD8530AS is primary side regulator (PSR) with built-in high voltage transistor. It provides built-in cable drop compensation and peak current compensation. It adopts PFM technology and provides accurate constant voltage, constant current (CV/CC) control loop for high average efficiency and reliability.

    Using SD8530AS for system design, few peripheral components are needed without requiring the Opto-coupler, Y capacitor, secondary control circuit and the loop compensation circuit which reduced the cost.

    6W output power is recommended for SD8530AS in range of AC85~264V.


Main feature

  • Built-in high voltage transistor

  • Primary side control

  • Low start-up current

  • Leading edge blanking

  • Pulse-Frequency Modulation

  • Overvoltage protection

  • Undervoltage lockout

  • Short circuit protection

  • Over temperature protection

  • Open Loop Protection

  • Cable drop compensation

  • Peak current compensation

  • Cycle by cycle current limiting


Ordering Information
Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
SD8530AS SOP-7-225-1.27 SD8530AS Halogen free Tube
SD8530ASTR SOP-7-225-1.27 SD8530AS Halogen free Tape & reel
Block Diagram

SD8530AS 英文（PS）.png
